Simplify layout and positioning jobs with unmatched speed and accuracy!
- Optics centered laser for verifiable accuracy
- up to 165 ft (50m) away (DT-200L series)
- Extremly low power consumption - 140 hours of operation from 4 AA batteries without laser
- Waterproof and dustprof
- Vertical angle correction provides + 3 minutes accuracy
- RS232C Data I/O Port
SPECIFICATION :
ANGLE MEASUREMENT
Accuracy
5"
Method
Absolute reading
Detecting
Horiz. 2 side
Vert. 1 side
Min. reading
1"/5"
0.5mgon/1mgon
Diameter circle
71mm (2.75")
TELESCOPE
Magnification
30x
Length
152mm (5.9")
Objective lens
45mm (1.7")
Field of view
1
o30'
Resolving power
2.5"
Minimum focus
1m (3.2')
Stadia ratio
100
Stadia constant
0
Sighting collimator
Double
LASER POINTER
Method
Focusing
Wave length / Power
633nm/0.6mW
Laser Class
Class II
DISPLAY
Unit
2 sides
LCD 7 segments
DATA OUTPUT
Serial signal connector
RS-232C
ILLUMINATION
Display
Yes
Reticle
Yes
COMPENSATOR
Tilt sensor
Vertical
Compensating range
+3'
OPTICAL PLUMMET
Magnification
3x
Field of view
3
o
Focusing
0.5m~∞
LEVEL SENSITIVITY
Plate level
40"/2mm
Circular level
10'/2mm
WATER PROTECTION
Standard
IP66
POWER SUPPLY
Battery
4AA batteries
OPERATING TIME
Theodolite only
140h
Laser only
80h
Theodolite And Laser
45h
OPERATING TEMPERATURE
-68
oF~+122F
(-20
oC~+50
oC)
WEIGHT
9lbs (4.1kg)
